PEDAL for CB1000R GRAPHITE BLACK (NHB01) from 2021

PEDAL for CB1000R GRAPHITE BLACK (NHB01) from 2021
Reference
Product name
#1 24705-MR7-000

RUBBER, GEAR CHANGE PEDAL

Price €10.86
#3 24711-MKF-D60

ARM, GEAR CHANGE

Price €86.54
#6 24724-MBW-D21

COVER, DUST

Price €16.73
#7 32214-MKJ-D10

STAY, STROKE SENSOR

Price €13.15
#9 35357-MCH-000

SPRING, STOP SWITCH

Price €8.11
#11 45423-KA4-700

NUT, HEX, 6MM (LEFT HAND THREAD)

Price €5.84
#14 90026-GHB-620

BOLT, FLANGE, 6X12 (S-NSHF)

Price €5.46
#15 90030-GHB-660

BOLT, FLANGE, 6X20

Price €5.83
#17 90113-MCF-000

BOLT, CHANGE PIVOT

Price €17.89
#18 90115-MKF-D60

BOLT, FLANGE, 7X30

Price €7.55
#21 90202-KV3-000 i

NUT, FLANGE, 7MM

Price €5.84
#22 90505-MBW-000

WASHER, CHANGE PEDAL WAVE

Price €8.00
#23 90557-230-000

WASHER, 152X25

Price €6.80
#24 90601-KAF-003

CLIP, SWITCH COVER

Price €6.23
#26 94002-060800S i

NUT, HEX, 6MM

Price €0.85
#27 94103-08700

WASHER, PLAIN, 8MM

Price €0.64
#28 94511-15000

CIRCLIP, EXTERNAL, 15MM

Price €0.94
#5 24720-MKJ-E60

PEDAL COMP, GEAR CHANGE

Price €127.58
#8 35350-MKJ-E51

SWITCH ASSY, RR STOP

Price €89.59
#10 36390-MKJ-E61

SENSOR ASSY, STROKE

Price €2,329.63
#12 46500-MKJ-E60

PEDAL COMP, RR BRAKE

Price €137.05
#13 46515-MKJ-E50

SPRING ASSY, BRAKE PEDAL

Price €16.26
#16 90065-ML0-900

BOLT, TIE ROD

Price €15.95
