WIRE HARNESS for CB1000R GRAPHITE BLACK (NHB01) from 2020

WIRE HARNESS for CB1000R GRAPHITE BLACK (NHB01) from 2020
Reference
Product name
#1 31600-MKJ-D01

RECTIFIER COMP, REGULATOR

Price €474.05
#2 31700-GFZ-J01

RESISTOR COMP

Price €19.08
#4 32100-MKJ-D02

HARNESS, WIRE

Price €1,105.03
#5 32146-S84-003

CONNECTOR, DIODE (2P) (3A)

Price €26.36
#6 32605-GEV-761

CAP, DUMMY (WPC 4P 090 M) (NATURAL)

Price €16.30
#7 32606-GEV-761

CAP, DUMMY (4P) (RED)

Price €10.15
#9 33714-KL3-620

RUBBER, TAILLIGHT BRACKET

Price €6.62
#10 33715-GB0-900

COLLAR, TAILLIGHT SETTING

Price €4.56
#11 35160-MGS-D31

SENSOR ASSY, BANK ANGLE

Price €328.60
#14 38110-KPP-T01

HORN COMP (HIGH)

Price €48.10
#15 38117-KFE-701

COLLAR, HORN SETTING

Price €18.05
#16 38221-SNA-A31

FUSE, BLADE (75A)

Price €5.34
#17 38221-SNA-A41

FUSE, BLADE (10A)

Price €5.69
#18 38221-SNA-A51

FUSE, BLADE (15A)

Price €5.83
#19 38255-MKJ-D00

COVER COMP, UPPER

Price €30.44
#21 38301-MKJ-D01

RELAY COMP, WINKER (LED)

Price €75.32
#22 38306-KK4-000

SUSPENSION, WINKER RELAY (MITSUBA)

Price €8.46
#23 38501-MEL-003

RELAY ASSY, POWER (MICRO ISO 4P)

Price €20.95
#24 38770-MKJ-D02

PGM-FI UNIT

Price €1,577.50
#25 50355-MKJ-D00

STAY, BANK ANGLE SENSOR

Price €22.27
#26 90020-GHB-640

BOLT, FLANGE, 6X16

Price €5.57
#27 90308-MT8-000

NUT, CAP, 6MM

Price €4.84
#28 90690-GHB-671

CLIP, CABLE, 25MM

Price €2.04
#29 90690-MEF-800

CLAMP, HARNESS

Price €4.45
#30 90851-961-000

RUBBER, TAILLIGHT MOUNTING

Price €13.79
#31 91535-TA0-003

CLIP, COUPLER (DARK BROWN)

Price €8.64
#32 94050-06080

NUT, FLANGE, 6MM

Price €1.18
#33 94103-06800

WASHER, PLAIN, 6MM

Price €0.77
#34 95701-0601608

BOLT, FLANGE, 6X16

Price €1.06
#35 95701-0601807

BOLT, FLANGE, 6X18

Price €0.94
#36 96001-0602500

BOLT, FLANGE, 6X25

Price €1.48
#37 31730-MAS-601

DIODE ASSY, THREE WAY (SUMITOMO)

Price €48.62
#38 98200-43000

FUSE, MINI (30A)

Price €1.81
