SEAT/LUGGAGE CARRIER for C125A PEARL NEBULA RED (R376) from 2019

SEAT/LUGGAGE CARRIER for C125A PEARL NEBULA RED (R376) from 2019
Reference
Product name
#1 36520-KSV-J03 i

ACTUATOR ASSY

Price €292.24
#7 77206-KPK-900

RUBBER, SEAT CUSHION

Price €4.14
#8 77206-KPP-T00

RUBBER, SEAT CUSHION

Price €5.74
#10 77208-KPW-900

COLLAR, SEAT MOUNTING

Price €3.28
#11 77215-KW7-900

RUBBER C, SEAT SETTING

Price €4.14
#14 77242-KSV-J00

JOINT, CABLE

Price €13.73
#17 93903-24310

SCREW, TAPPING, 4X12

Price €0.64
#18 93903-34510

SCREW, TAPPING, 4X20

Price €0.64
#19 93913-14220

SCREW, TAPPING, 4X12

Price €0.64
#20 94001-060000S i

NUT, HEX, 6MM

Price €1.19
#21 94021-060000S i

NUT, CAP, 6MM

Price €1.78
#22 94103-06000 i

WASHER, PLAIN, 6MM

Price €0.85
#23 95701-0601208 i

BOLT, FLANGE, 6X12

Price €1.08
#2 77100-K0G-901ZA

SEAT COMP, SINGLE TYPE2 (TYPE2 )

Price €297.23
#3 77110-K0G-900

HINGE COMP, SEAT

Price €33.32
#4 77116-K0G-900

RUBBER, CUSHION

Price €4.76
#5 77117-K0G-900

HOOK, HELMET

Price €17.72
#6 77156-K0G-901

CABLE COMP, SEAT LOCK

Price €10.54
#9 77207-GN5-910

RUBBER B, SEAT MOUNTING

Price €4.14
#12 77230-K0G-900

CATCH COMP, SEAT

Price €46.82
#13 77234-GGZ-J00

SPRING, SEAT LOCK

Price €5.00
#15 77250-K0G-900

STAY, ACTUATOR

Price €14.99
#16 83405-K0G-900

COVER, SEAT HINGE

Price €26.94
