BEARING SET, NEEDLE
CAP, TAPPET ADJUSTING HOLE
GEAR ASSY, FINAL
RING, STOPPER
GEAR SET, FINAL
CASE SUB ASSY, FINAL GEAR
COVER SUB ASSY, FINAL GEAR
RETAINER, BEARING
LOCK A, BEARING ADJUSTING (SINGLE TAB)
LOCK B, BEARING ADJUSTING (DOUBLE TABS)
STAY A, FINAL GEAR COVER
STAY B, FINAL GEAR COVER
JOINT, PINION
SHIM A, PINION GEAR (132)
SHIM B, PINION GEAR (138)
SHIM C, PINION GEAR (144)
SHIM D, PINION GEAR (150)
SHIM E, PINION GEAR (156)
SHIM F, PINION GEAR (162)
SHIM G, PINION GEAR (168)
SHIM A, SHAFT (173)
SHIM B, SHAFT (176)
SHIM C, SHAFT (179)
SHIM D, SHAFT (182)
SHIM E, SHAFT (185)
SHIM F, SHAFT (188)
SHIM G, SHAFT (191)
SHIM H, SHAFT (194)
SHIM I, SHAFT (197)
SHIM J, SHAFT (200)
SHIM K, SHAFT (203)
SHIM L, SHAFT (206)
SHIM M, SHAFT (209)
SHIM N, SHAFT (212)
SHIM O, SHAFT (215)
SHIM P, SHAFT (045)
SHIM A, RING GEAR (182)
SHIM B, RING GEAR (188)
SHIM C, RING GEAR (194)
SHIM D, RING GEAR (200)
SHIM E, RING GEAR (206)
SHIM F, RING GEAR (212)
SHIM G, RING GEAR (218)
SHIM H, RING GEAR (224)
SHIM I, RING GEAR (230)
SHIM J, RING GEAR (236)
SHIM K, RING GEAR (242)
SHIM L, RING GEAR (248)
SHIM M, RING GEAR (254)
SHIM N, RING GEAR (260)
SHIM P, RING GEAR (266)
GROMMET, AIR CLEANER CASE
BOLT, SOCKET, 8X11
BOLT, STUD, 12X46
BOLT, FLANGE, 8X30
BOLT, FLANGE, 10X38
NUT, HEX, 16MM
PACKING, 8MM
BEARING, RADIAL BALL, 100X125X13
BEARING, RADIAL BALL, 30X55X18
BEARING, RADIAL BALL (QJ3/28V1)
OIL SEAL, 39X56X7
OIL SEAL, 997X117X7
O-RING, 308MM
O-RING, 645X35 (ARAI)
TUBE, FINAL GEAR BREATHER
BOLT, HEX, 6X12
BOLT, STUD, 10X40
PIN A, DOWEL, 12X16
CLIP, TUBE (B7)
BOLT, FLANGE, 6X12
